Product Specifications:
~ 3 Channels: [Front+Interior+Rear]
~ Screen size: 2 inches
~ File format: AVI
~ Voltage 1 Current: 5V/1A
~ Video resolution: 1080P; 720P; VGA
~ Continuour Loop Video: Seamless Loop Recording
~ Automatic power on/off: support automatic ignition and shutdown
~ Interface: Support USB
~ Time Synchronization: Support
~ Support memory card: TF (maximum support 64GB)
~ Built-in stereo: support
~ Frequency: 50HZ / 60HZ
Attention:
The recorder needs to be equipped with a high-speed C10 or higher memory card for normal use. It is recommended to buy memory card packaging in this store to avoid adverse reactions to the product due to the purchase of irregular memory cards!
Power Source: Corded Electric
APP Compatibility: Viidure
Built-in Screen: YES
Loop-Cycle Recording Feature: YES
Audio Recorded: YES
Maximum Video Frame Rate: 30
NightShot Function: YES
Rear Camera: YES
Display: IPS
Original Package: YES
Touch Screen: No
Screen Ratio: 16:9
Memory Card Required Reding Speed: Class 10
View angle: 170
Camera Resolution: 1920x1080
Video Code: MJPG
Video Format: AVI
Special Features: digital zoom,motion detection,sd/mmc card,Anti Surge Voltage Impact,Anti Fog,Anti Vibration,Real Time Surveillance,Automatic White Balance,Wide Dynamic Range,wifi function,Parking Monitor
Max External Memory: 128G
Number Of Lenses: 3
Imaging Sensor: OV7670
OSD Language: Arabic,Chinese (Simplified),English,French,German,HEBREW,Italian,Portuguese,RUSSIA,Spanish,THAI,Turkish
GPS logger: NONE
Interface: AV-In,HDMI,Micro SD/TF
About Formatting The Memory Card:
When installing a memory card for the first time, be sure to format the memory card on the DVR. After formatting, the DVR can correctly match the memory card.
Formatting Steps:
After installing the memory card, Long press the "M" key to enter the DVR menu, find the format option, and click to format the memory card (Important: Formatting the memory card on the computer is an incorrect operation. Please be sure to format the memory card on the DVR's menu option.)
About The Reversing Assist Function:
If the kit you ordered includes a rearview camera and you need to implement the reversing assist function, you need to connect the red signal wire of the rearview camera to the car's reversing light (the light will come on when reversing). If you don't need the reverse assist function, just disconnect the red signal wire and leave it unconnected.
About 24-Hour Parking Monitoring:
If you need the 24 hour parking monitoring function, you can order the corresponding Buck Line accessories to replace the car charger.Through Buck Line, the DVR power can be obtained directly from the car battery or car ACC, so that the DVR can maintain normal recording work even when the car is turned off.(Since different car models have different battery interfaces or ACC interfaces, it is not recommended to install it by yourself. It is recommended to find a professional to install the Buck Line.)
